| Engine |
Loncin LC2P77F Start elettrico con batteria 12v Supply benzina 708 cc, 2 Cylinders 22.0 HP, 16.0 KW Raffreddato ad aria Filtro aria a secco |
| Fuel tank capacity | 13 L |
| Transmission | Hydrostatic |
| Traction | 4WD |
| PTO | Electromagnetic clutch with flat belt |
| Differential locking | Differencial lock by pedal action |
| Cutter deck | Single-blade rear discharge deck |
| Cutting deck width | 103 cm |
| Cutting width | 93 cm |
| Cutting height | From 3.5 to 13.5 cm, with continuous adjustment |
| Front tyres | 4.00–8 TRACTOR and puncture-proof treated |
| Rear tyres | 20 x 10.00-8 TRACTOR |
| Steering system | Steering wheel, with forward and reverse lever |
| Speed | From 0 to 9 km/h, reverse from 0 to 8 km/h |
| Inner turning radius | 76 cm |
| Seat | Comfort seat, cushioned and adjustable. With roll bar |
| Brakes | Parking brakes on rear wheels with lever control |
| Mowing capacity per hour (indicative) | 7200 m²/h |
| Length | 206 cm |
| Width | 103 cm |
| Height | 118,5 cm |
| Weight | 350 kg |
