| Engine |
Norwik SH186FA Start recoil starter and electric with 12V battery Supply diesel 418 cc, 1 Cylinder 8.8 HP, 6.6 KW Air cooled Dry air filter |
| Fuel tank capacity | 5.5 L |
| Transmission | With oil bath gears |
| Gearbox | With clutch engagement. The walking tractor version has 2 forward gears + 2 reverse gears. The sickle bar version has 2 forward gears + 2 reverse gears |
| Reverse gear unit | By lever |
| Clutch | Conic active |
| Differential locking | Differential with locking device by lever on the handlebar |
| Standard rotary tiller | Adjustable rotary tiller with x 4 tines. Working width 58 cm |
| Hoes system diametre | 32 cm |
| Working width | Adjustable at 37 and 47 cm |
| Working depth | 16 cm |
| P.T.O. | 965 rpm independent of the gearbox. Clockwise rotation for the walking tractor version, anticlockwise rotation for the sickle bar version |
| Available tyres | Pneumatic wheels tractor 4.00-8 (fixed disks), 4.00-10 (adjustable disks) and 5.00-10 (adjustable disks). Pneumatic wheels tractor 5.00-12 (adjustable disks) for plough kit. Wide steel wheels having diameter 40 x 10 cm. Pneumatic wheels garden 20x10.00- |
| Speed | With 4.00-10 wheels 1st gear 1,2 km/h, 2nd gear 3,0 km/h |
| Service brake | Brake drum (kit upon request) |
| Handlebar | Height and side adjustment. Fitted on anti-vibration blocks |
| Safety devices | Active clutch, reverse speed – PTO cut-out |
| Weight | 162 kg |
